Description
It is a technically solid device with outstanding specifications, capable of taking your system to new and impressive sound levels.
Additionally, it is designed to easily interact with modern systems, featuring speaker-level signal inputs, automatic turn-on, a remote output to switch on amplifiers, and an External Bass Control with dual functionality: Gain and Restoration Level.
Features:
- Digital Low-Frequency Restoration
- Line-Level Inputs (RCA)
- High-Level Inputs with impedance emulator
- Automatic turn-on when using High-Level Inputs
- Three different Restoration intensities
- Remote-on Output
- External controller with dual function: Bass Restoration Level and Output Gain
- Subsonic Filter
Specifications:
Frequency Response: 10–30,000 Hertz
Total Harmonic Distortion (THD): < 0.05%
Signal-to-Noise Ratio: >105 dB
Subsonic (Infrasonic) Filter: 4th order @ 22 Hertz
Maximum RCA Input Voltage: 9 Volts RMS
Maximum High-Level Input Voltage: >40 Volts RMS (400 watts)
Maximum Output Voltage before distortion: 9 Volts RMS
RCA Input Impedance: >20 kΩ
High-Level Input Impedances: 20, 60, and 20 kΩ
Output Impedance: <150 Ω
Recommended Fuse: 1 Ampere
